% of Rating | 210% | 275% | 400% | 1000% | ||
250mA–6.3A | Max | Min | Max | Min | Max | Max |
2min | 600ms | 10s | 150ms | 3s | 300ms |
额定电流 | 额定电压(AC) |
250 mA | 125V/250V |
315 mA | 125V/250V |
400 mA | 125V/250V |
500 mA | 125V/250V |
630 mA | 125V/250V |
800 mA | 125V/250V |
1.0 A | 125V/250V |
1.25 A | 125V/250V |
1.6 A | 125V/250V |
2.0 A | 125V/250V |
2.5 A | 125V/250V |
3.15 A | 125V/250V |
4.0 A | 125V/250V |
5.0 A | 125V/250V |
6.3 A | 125V/250V |
8A | 125V/250V |
10A | 125V/250V |
12.5A | 125V/250V |
16A | 125V/250V |
